Products >> Cantilever formwork
The system formwork has two kinds which the platform is 2.0m and 2.4m wide. It’s widely used in construction of pier, high building and so on with different kinds of formwork. The concrete lateral pressure is entirely supported by tie-rod and anchor system. It’s light in weight and convenient in use which the main parts are easy to assemble or remove.
lThe concrete pressure is supported by the tie-rod and other loads by the anchor system. It’s suitable for high structure construction.
lThe formwork and upper bracket can be removed backward 600mm which will be convenient for work. The maximum pouring height is 6m.
lThe formwork is flexible to adjust from all directions and can be inclined forward and backward.
lThe connecting components have a high standardization and versatility. It’s easy for transportation and storage.
lThe suspended platform is convenient for remove the anchor system and treat the concrete surface.
lThe formwork bottom can prop to the finished concrete tightly to avoid offset and leakage.
